| Tehničke karakteristike |
|
|
Power Device Type:
|
Power Supply
|
|
Power Device Location:
|
Plug-in-module
|
|
Form Factor:
|
ATX
|
|
Input Voltage:
|
AC 100-240 V
|
|
Input Frequency:
|
50/60 Hz
|
|
Rated Input Current:
|
10 A
|
|
Maximum Output Power:
|
750 W
|
|
Circuit Protection:
|
Over Voltage
Undervoltage
Over Current
Short Circuit Protection
Over Power
|
|
Power Adapter and Power Supply Features:
|
Active PFC
Low noise
|
|
80 Plus Certification:
|
80 Plus Bronze
|
|
Efficiency:
|
89%
|
|
+3.3V:
|
22 A (70 W)
|
|
+5V:
|
22 A (70 W)
|
|
+12V:
|
62.5 A (750 W)
|
|
-12V:
|
0.3 A (3.6 W)
|
|
+5VSB:
|
3 A (15 W)
|
|
20+4-pin Main Connector:
|
1
|
|
4/8-pin +12V Power Connector:
|
2
|
|
4-pin Peripheral Power Connector:
|
3
|
|
S-ATA Connector:
|
8
|
|
6/8-pin PCI Express Connector:
|
4
|
|
Fans Installed Quantity:
|
1
|
|
Fan Diameter:
|
120 mm
|
|
Maximum Operating Ambient Temperature:
|
40 °C
|
|
Minimum Operating Ambient Temperature:
|
10 °C
|
|
Maximum Operating Humidity:
|
85 %
|
|
Minimum Operating Humidity:
|
20 %
|
|
Maximum Non-Operating Ambient Temperature:
|
70 °C
|
|
Minimum Non-Operating Ambient Temperature:
|
-40 °C
|
|
Maximum Non-Operating Humidity:
|
95 %
|
|
Minimum Non-Operating Humidity:
|
5 %
|
|
External Color:
|
Black
|
|
Included Accessories:
|
Quick Start Guide
|
|
Warranty Products Returnable:
|
Yes
|
|
Warranty Term (month):
|
24 month(s)
|
|
Warranty validation Criteria:
|
Serial Number
|
|
Pack Weight Brutto (kg):
|
2.13 kg
|
|
Pieces in pack:
|
1
|
|
Box Weight Brutto (kg):
|
19.9 kg
|
|
Packs in Box:
|
9
|
|
Package Type:
|
Box
|
|
EAN Code:
|
4710483774881
|
|
Boja:
|
Crna
|
|
Dodaci:
|
Brzi priruÄŤnik
|
|
Jamstvo u Hrvatskoj:
|
Da
|
|
Jamstveni rok (mjeseci):
|
24 mjeseci(a)
|
|
Validacija jamstva:
|
Serijski broj
|
|
Bruto teĹľina (kg):
|
2.13 kg
|
|
KoliÄŤina u pakiranju:
|
1
|
|
Bruto teĹľina kutije (kg):
|
19.9 kg
|
|
KoliÄŤina u kutiji:
|
9
|
|
Tip pakiranja:
|
Box
|
|
EAN kod:
|
4710483774881
|
|
Economic operator in EU / authorized representative:
|
COMPUCASE Enterprise Co., Ltd.
|
|
Postal address:
|
No. 225, Lane 54, An-Ho Rd., Sec.2, Tainan, Taiwan R.O.C.
|
|
Electronic address:
|
[email protected]
|
|
Vrsta napajanja:
|
Napajanje
|
|
Napajanje:
|
Plug-in modul
|
|
Format:
|
ATX
|
|
Ulazna struja:
|
10 A
|
|
Izlazna snaga:
|
750 W
|
|
Zaštita strujnog kruga:
|
Over Voltage
Undervoltage
Over Current
Short Circuit Protection
Over Power
|
|
ZnaÄŤajke adaptera i napajanja:
|
Active PFC
Low noise
|
|
Promjer:
|
120 mm
|
|
Max. radna temperatura:
|
40 °C
|
|
Min. radna temperatura okoline:
|
10 °C
|
|
Max. radna vlaĹľnost:
|
85 %
|
|
Min. radna vlaĹľnost:
|
20 %
|
|
Max. neradna temperatura:
|
70 °C
|
|
Min. neradna temperatura:
|
-40 °C
|
|
Max. neradna vlaĹľnost:
|
95 %
|
|
Min. neradna vlaĹľnost:
|
5 %
|
|
Neto teĹľina (kg):
|
1.83 kg
|
|
Vrsta pakiranja:
|
Box
|
