| Tehničke karakteristike |
|
|
Model:
|
RT-AX58U V2
|
|
Priključci:
|
1 x RJ45 for Gigabits BaseT for WAN
4 x RJ45 for Gigabits BaseT for LAN
1 x USB 3.2 Gen 1
|
|
Standard:
|
IEEE 802.11a (do 54 Mbps)
IEEE 802.11b (do 11 Mbps)
IEEE 802.11g (do 54 Mbps)
WiFi 4 (802.11n) (do 300 Mbps)
WiFi 5 (802.11ac) (do 1733 Mbps)
WiFi 6 (802.11ax) (2.4GHz do 574 Mbps)
WiFi 6 (802.11ax) (5GHz do 2402 Mbps)
IPv4
IPv6
|
|
Antena:
|
Četiri eksterne antene
|
|
Mod rada:
|
Wireless router mode
Access point mode
Media bridge mode
Repeater mode
AiMesh node mode
|
|
Radna frekvencija:
|
2.4G Hz / 5 GHz
|
|
Karakteristike:
|
Procesor: 1.7 GHz quad-core procesor
Memorija: 256 MB Flash?512 MB RAM
Tipke: WPS Button, Reset Button, Power Switch
LED indikatori: Power x 1?2.4G x 1?5G x 1?LAN x 4?WAN x 1
|
|
Sigurnost:
|
AiProtection
WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
SSH
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
|
|
Napajanje:
|
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A
Current DC Output : 12 V with max. 2 A current
|
|
Dimenzije i masa:
|
224 x 129 x 160 mm (s antenom)
523 g
|
|
Sadržaj pakiranja:
|
RT-AX58U WiFi router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card
|
|
AiProtection:
|
• Router Security Assessment
• Malicious Site Blocking
• Two-Way IPS
• Infected Device Prevention and Blocking
|
|
VPN:
|
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
|
|
Traffic Control:
|
Adaptive QoS
• Bandwidth Monitor
• Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
-- Maximum Traditional QoS Rule : 32
Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
Traffic Analyzer
• Traffic Analysis Period : Daily, Weekly, Monthly
• Website History
|
|
WAN:
|
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
3G / 4G LTE dongle
Port forwarding
• Maximum Port Forwarding Rule : 64
Port triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
|
|
LAN:
|
DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
|
|
Wireless:
|
UTF-8 SSID
WiFi MAC Address Filter
• Maximum MAC Filters : 64
Wireless Scheduler
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming
|
